APEX MARS LANDER w/ SERVICE MODULE
Meant to be Spawned in Earth Orbit;
(Designed for Trans MARS Injection, Capture, Soft Touchdown, Return to Martian Orbit, Trans Earth Return.)
. Credit: Uses Docking Assistant UI Vizzy, by:
“GoldenShadowGS”
APEX SPACECRAFT FEATURES;
APEX MARS CAPSULE;
. Stock JUNO Capsule
. Null Vectors Docking Assist [AG2 >5km)
. RCS-Stage Activated w/ [OR]
. Hull Lighting-Stage Activated w/ [OR]
. Dock & Capsule Beacon Lighting - Stage Activated
. Docking Light
. Dock Cam
. Four HIGH Altitude Deceleration Parachutes - Staged Activated w/ Lander Stage (Orange & White)
. Four LOW Altitude Parachutes - Staged Activated w/ Capsule (Red & White)
APEX MARS LANDER / TRUNK STAGE;
. Single ION Engine
. RCS-Stage Activated w/ [OR]
. Landing Mode
. Quad Stage Separation Motors
APEX MARS SERVICE MODULE;
. Single Methalox Engine (Orange Plume)
. MARS Injection - Capture Capable DELTA-V
. RCS-Stage Activated w/ [OR]
. Quad Stage Separation Motors
Mission Notes:
. Slider 1+ to Deploy Antenna’s
. De-Orbit from 100km MARS Orbit, w/ 1/2 Orbit Rotation
. High Altitude Parachutes Deploy at 50km
. Cut High Altitude Parachutes for MARS Accent
As always, Enjoy JUNO Friends!
CanadaDucK
GENERAL INFO
- Predecessor: ARROW HEAD ROCKET
- Successors 4 craft(s)
- Created On: iOS
- Game Version: 1.2.109.0
- Price: $286,989k
- Number of Parts: 165
- Dimensions: 8 m x 3 m x 3 m
PERFORMANCE
- Total Delta V: 7.4km/s
- Total Thrust: 475kN
- Engines: 10
- Wet Mass: 25,932kg
- Dry Mass: 10,636kg
STAGES
| Stage | Engines | Delta V | Thrust | Burn | Mass |
|---|---|---|---|---|---|
| 1 | 1 | 2.6km/s | 387kN | 2.0m | 25,932kg |
| 2 | 1 | 4.8km/s | 74kN | 6.0m | 6,085kg |
| 3 | 0 | 0m/s | 0N | 0s | 2,508kg |
5 Comments
- Log in to leave a comment
-
2,237 TomKerbal+1 1.5 years ago
@CanadaDucK Again so awesome ! I really like it, esp. I am also currently at Mars.
Is it really possible to do this mission with 7.4 km/s ? Well, TMI needs only 4.3km/s (9 month travel time then) I have learned recently at KSP1/RP-1 . So that (robotic) Apollo style mission wouldn't be so expensive. This nice craft has only 26t, easy to bring in Eath orbit. Really nice :-)
(I think in HyperPatch Solar System 2.0 Mars atmosphere height is 115km, to deorbit should be at 120km there) -
-
-
Very nice. Great esthetics.
